ORACLE Lighting 2006-2020 Toyota 4Runner H11 - S3 Pro LED Conversion Kit (Low Beam)
Product Overview ▼
The ORACLE S3 LED Conversion Bulbs instantly provide 3,200 lumens of crystal-clear 6000K light output in a low-profile, all-in-one package. Unlike traditional LED conversion kits that require separate external drivers and cooling fans, the S3's electronic components are housed in a sealed waterproof heat-sink design - everything is integrated directly into the bulb body.
The CSP (Chip Scale Package) LED chip design features a small package size with high-intensity output per unit and less heat generation, resulting in industry-leading luminous efficacy of 130 lm/W. This new low-profile design significantly reduces common bulb fitment issues, making installation a true plug-and-play experience on a wide range of vehicles.
Key Features ▼
- 3,200 lumen output - crystal-clear 6000K bright white light
- CSP (Chip Scale Package) LED chip - small package, high intensity, low heat generation
- 130 lm/W luminous efficacy - industry-leading efficiency ratio
- Integrated sealed waterproof heat sink - driver built directly into the bulb, no external components
- No external drivers or cooling fans - cleaner install, fewer points of failure
- Low-profile design - reduces fitment issues across a wide range of vehicles
- 12W per bulb - under 1 amp current draw, minimal load on factory wiring
- Double-layer copper PCB - improved thermal performance and reliability
- 6160 aluminum construction - lightweight, durable heat dissipation
- 12V/24V compatible - works with standard and heavy-duty vehicle electrical systems
- Easy plug-and-play DIY installation
- 1-year limited warranty
Performance & Technical Specifications ▼
Vehicle Fitment ▼
Vehicle Fitment: 2006-2020 Toyota 4Runner.
Bulb and Application: H11 low beam headlight.
What's Included ▼
- (2) ORACLE S3 H11 LED Fog Light Bulbs
Installation Guide & Resources▼
Access the factory light housing, remove the original bulb, install the ORACLE LED bulb in the factory socket, and test operation before reassembly.
Experience Level: Intermediate
Basic mechanical or electrical familiarity is recommended.
Certifications & Downloads
